Kuchinoerabujima

Photo of this volcano
  • Country
  • Volcanic Region
  • Primary Volcano Type
  • Last Known Eruption
  • 30.443°N
  • 130.218°E

  • 639 m
    2096 ft

  • 282050
  • Latitude
  • Longitude

  • Summit
    Elevation

  • Volcano
    Number

Most Recent Weekly Report: 15 June-21 June 2016 Citation IconCite this Report


On 14 June JMA reported that no activity at Kuchinoerabujima had been detected after a small eruption on 19 June 2015. The report noted that volcanic tremor had not been detected, the temperature of thermal areas had declined, sulfur dioxide gas flux was lower than values detected prior to the May-June 2015 eruption, and volcanic earthquake levels were lower than levels detected in August 2014. The Alert Level was lowered to 3 (the highest level on a 1-5 scale) on 14 June, and the public was reminded to stay at least 2 km away from Shindake Crater.

Source: Japan Meteorological Agency (JMA)


Most Recent Bulletin Report: March 2017 (BGVN 42:03) Citation IconCite this Report


Explosions on 3 August 2014, 29-30 May 2015 (with pyroclastic flow), and 18-19 June 2015

Intermittent ash explosions during the last century have characterized activity at Japan's Kuchinoerabujima volcano, located at the northern end of the Ryukyu Islands approximately 260 km S of Nagasaki, Japan. Brief periods of higher seismicity had been detected in the last approximately 30 years, although no explosions had been recorded since 1980 (BGVN 35:11 and 38:01). A new explosion occurred on 3 August 2014, and activity remained elevated through June 2015. Information on the latest activity is provided by the Japan Meteorological Agency (JMA) monthly reports and aviation alerts are from the Tokyo Volcanic Ash Advisory Center (VAAC).

A modest explosion from Shindake crater on 3 August 2014 caused JMA to increase the Alert Level at the volcano. Activity decreased shortly after the explosion, and only steam plumes, fumarolic activity, and occasional incandescence were observed for the next nine months. A large explosion on 29 May 2015 generated a gray-black ash plume that rose to over 9 km altitude and sent pyroclastic flows down the flanks; JMA increased the Alert Level and ordered evacuation of local residents. Activity declined after a few days, and Shindake remained quiet until a smaller explosion on 18 June 2015. The ash plume did not exceed 1 km, but ashfall was reported in towns on neighboring islands and in areas up to 80 km E. Two additional smaller explosions were reported on 18 and 19 June. Seismicity decreased significantly after the 19 June explosion, but SO2 emissions remained elevated until October 2015. The JMA did not lower the Alert Level until June 2016.

Activity during August 2014-February 2015. JMA reported an eruption from the vicinity of Shindake crater around noon local time on 3 August 2014, with a gray plume rising more than 800 m above the crater rim. This led to an increase in the Alert Level from 1 (Normal) to 3 (Do not approach the volcano) on a 5-level scale. An overflight confirmed traces of ash on the W flank. The Tokyo VAAC reported that the plume rose to an altitude greater than 1.5 km and drifted N. On 5 August, seismicity decreased, and views from a remote web camera showed a white plume rising 50 m above the crater rim. For the rest of August, seismicity remained low and steam plumes rose 50 to 800 m above the crater.

During September 2014, white plumes were generally observed 200-800 m above the crater when visibility was not obscured by weather; seismicity remained low. Scientists conducting a field survey on 12 September found SO2 emissions at 300 metric tons per day (t/d), higher than the background value of 60 t/d measured on 21 May 2014. Occasional earthquakes were recorded in October 2014, and the volume of gas emissions remained relatively high compared with before the August eruption; steam-and-gas plumes rose to 600 m above the crater rim. During field surveys on 7 and 8 October scientists measured SO2 emissions of 500 t/d. Gas emissions rose from within the Shindake crater, around a thermally anomalous fissure at the W edge of the crater, as well as from a new fumarole on the SW flank of the crater. In November, plumes continued to rise as high as 1,000 m above the crater. In another survey on 9 December 2014, scientists found that SO2 levels had increased to 1,700 t/d.

Emissions of SO2 remained high during the second half of January 2015, ranging from 1,100 to 3,100 t/d. A M 2.2 seismic event located 5 km beneath the island was recorded on 24 January. Observations made during field surveys in February confirmed continued steam emissions, and thermal anomalies from the W crater rim fissure and the new fissure on the SW flank. SO2 emissions decreased slightly from January levels to a range of 400 to 2,700 t/d in February, and steam plumes continued to rise 400-700 m above the crater.

Activity during March-June 2015. Incandescence at night was first recorded at the Shindake Crater from 24 to 31 March 2015 with a high-sensitivity camera. Aerial observation on 25 March by JMA and JCG (Japan Coast Guard) indicated a temperature rise and continued fumarolic activity around the thermal anomaly W of the crater rim. SO2 emissions remained high in March (1,000 to 3,700 t/d) and April (900 to 2,600 t/d), and steam plumes rose to 1 km above the crater. Incandescence was occasionally observed at night during April and again during 18-22 May; fumarolic activity continued along with a rise in temperature at the W and SW fissures. Steam plumes were observed rising to 600 m above the crater in May.

According to JMA, at 0959 local time on 29 May 2015, a large explosive phreatomagmatic eruption generated a gray-black ash plume that rose to over 9 km altitude and drifted ESE (figure 5). The plume was reported by the Tokyo VAAC to be at 10.9 km altitude about an hour after the eruption. The largest of several pyroclastic flows descended NW from the SW side of the crater in the Mukaehama district and reached the coast. Based on these events, JMA raised the Volcanic Alert Level to 5 (Evacuate). Aerial observation conducted on the same day (in collaboration with the Kyushu Regional Bureau of the Ministry of Land, Infrastructure, Transport and Tourism) revealed additional pyroclastic flows moving in nearly all directions from the Shindake crater (figure 6) including flows reaching halfway down the mountain to the SW and SE of the crater. Seismicity increased immediately after the eruption, but had decreased by midday.

Figure (see Caption) Figure 5. Ash plume from Kuchinoerabujima's Shindake Crater during an explosion on 29 May 2015. The plume height was reported by the Tokyo VAAC as 10.9 km altitude. Photo taken from the neighboring island of Yakushima by Itaru Takaku. Courtesy of Kyodo News and The Japan Times.
Figure (see Caption) Figure 6. Google Earth imagery dated 5 June 2015, one week after a large explosion which generated several pyroclastic flows around the summit crater at Kuchinoerabujima. Note the brown areas extending in most directions away from the summit crater (beneath the white clouds), all the way to the coast on the NW and W flanks that are the result of the pyroclastic flows that occurred on 29 May 2015. Courtesy of Google Earth.

According to a news article (The Japan Times), all residents and visitors (141 people) were safely evacuated by a ferry, coast guard ship, and helicopter to neighboring Yakushima Island (25 km SE). A resident of Yakushima reported that ash reached the island. Later that day, ash plumes rose 200 m and drifted SW.

Ash plumes continued the next day, 30 May, rising only 1.2 km. A field team observed discolored trees on the SE and SW flanks, and fallen trees near the coast on the NW flank. Cloud cover prevented views of the eruption area, but the team was able to confirm continued fumarolic activity and incandescence in the W part of the crater. Seismicity continued at low levels, and during the first week of June white plumes rose 100-400 m above the crater rim.

Another smaller eruption on 18 June 2015 caused lapilli and ash to fall on the E side of the island. Ash was reported in Yakushima Town (44 km ESE on Yakushima Island), Nishinoomote City (80 km NE on Tanegashima Island), and Nakatane Town (72 km E on Tanegashima). Small eruptions also occurred at 1631 on 18 June and at 0943 on 19 June. Tokyo VAAC reported the larger 18 June eruption, but plume heights were below 1 km, and not observed on satellite. Aerial observations on 20 June by JMA revealed no traces of new pyroclastic-flow deposits around the crater or on the flanks.

Post-eruption observations through June 2016. Emissions of SO2 remained elevated during June 2015 (800-1,700 t/d), and decreased somewhat in July to 500-700 t/d. They decreased further to 200-300 t/d in August. Increased seismicity was recorded briefly from 1-3 and 6-11 August. SO2 emissions continued to decline in September, except for a spike of 700 t/d on 10 September. Thermal infrared observations taken during a field survey in October 2015 indicated a decrease in temperature around the fissure W of the crater rim since the 29 May eruption. Emissions of SO2 remained below 300 t/d for the remainder of 2015 and no further activity was reported, although the Alert Level remained at 5. On 14 June 2016, JMA lowered the Alert Level to 3; seismic activity and SO2 flux values were below levels detected prior to the May-June 2015 eruption.

Information Contacts: Japan Meteorological Agency (JMA), Otemachi, 1-3-4, Chiyoda-ku Tokyo 100-8122, Japan (URL: http://www.jma.go.jp/jma/indexe.html); Tokyo Volcanic Ash Advisory Center (VAAC), 1-3-4 Otemachi, Chiyoda-ku, Tokyo, Japan (URL: http://ds.data.jma.go.jp/svd/vaac/data/); Google Earth (URL: https://www.google.com/earth/); The Japan Times (URL: http://www.japantimes.co.jp/news/2015/05/29/national/volcano-erupts-isle-kagoshima-prompting-evacuation-order/.

Weekly Reports - Index


2016: June
2015: January | February | March | April | May | June
2014: July | August | September | October | November | December
2009: March
2008: October


15 June-21 June 2016 Citation IconCite this Report


On 14 June JMA reported that no activity at Kuchinoerabujima had been detected after a small eruption on 19 June 2015. The report noted that volcanic tremor had not been detected, the temperature of thermal areas had declined, sulfur dioxide gas flux was lower than values detected prior to the May-June 2015 eruption, and volcanic earthquake levels were lower than levels detected in August 2014. The Alert Level was lowered to 3 (the highest level on a 1-5 scale) on 14 June, and the public was reminded to stay at least 2 km away from Shindake Crater.

Source: Japan Meteorological Agency (JMA)


3 June-9 June 2015 Citation IconCite this Report


JMA reported that during 3-8 June white plumes rose 100-400 m above Shindake Crater's rim at Kuchinoerabujima. Volcanic earthquakes had declined on 30 May but continued to periodically occur. The Alert Level remained at 5 (the highest level on a 1-5 scale).

Source: Japan Meteorological Agency (JMA)


27 May-2 June 2015 Citation IconCite this Report


JMA reported that at 0959 on 29 May an explosive and phreatomagmatic eruption at Kuchinoerabujima generated an ash plume that rose 9 km above Shindake Crater's rim and drifted ESE. Pyroclastic flows descended the SW flank and reached the coast on the NW flank. Volcanic earthquakes increased after that event, but then decreased around 1300. The Alert Level was raised to 5 (the highest level on a 1-5 scale). According to a news article all residents and visitors (137-141) were safely evacuated by a ferry to neighboring Yakushima Island. Later that day ash plumes rose 200 m and drifted SW. Scientists conducted an overflight and confirmed pyroclastic flow deposits on the NW and NE flanks.

Ash plumes continued to be emitted the next day, rising as high as 1.2 km. A field team observed discolored trees on the SE and SW flanks, and fallen trees near the coast on the NW flank. Cloud cover prevented views of the eruption area, but the team was able to confirm continued fumarolic activity from a crack in the W part of the crater as well as incandescence.

Source: Japan Meteorological Agency (JMA)


20 May-26 May 2015 Citation IconCite this Report


JMA reported that no eruptions occurred from Kuchinoerabujima during 18-22 May, although the level of activity remained elevated. White plumes rose 600 m above Shindake Crater, and incandescence from the W part of the crater was observed at night. Volcanic earthquakes were detected; tremor was absent. Fumarolic activity in a crack in W part of the crater was observed during a field survey. The Alert Level remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


1 April-7 April 2015 Citation IconCite this Report


JMA reported that no eruptions occurred from Kuchinoerabujima during 30 March-3 April, although the level of activity remained elevated. White plumes rose 1 km above Shindake Crater, and incandescence from the crater was observed at night. Volcanic earthquakes were detected; tremor was absent. Fumarolic activity in a crack in W part of the crater was observed during a field survey on 30 March. In addition the temperature of a thermal anomaly in the W part continued to rise. The Alert Level remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


25 March-31 March 2015 Citation IconCite this Report


JMA reported that no eruptions occurred from Kuchinoerabujima during 27-30 March, although the level of activity remained elevated. White plumes rose 1 km above Shindake Crater. Continuing fumarolic actiivty in a crack in W part of the crater was confirmed during a field survey. In addition the temperature of a thermal anomaly in the W part continued to rise. Low-level seismicity continued. The Alert Level remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


18 February-24 February 2015 Citation IconCite this Report


JMA reported that no eruptions occurred from Kuchinoerabujima during 16-20 February, although the level of activity remained elevated. White plumes rose 600 m above the crater. Low-level seismicity continued and tremor was absent. The Alert Level remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


11 February-17 February 2015 Citation IconCite this Report


JMA reported that no eruptions occurred from Kuchinoerabujima during 9-16 February although the level of activity remained elevated. White plumes rose 400-700 m above the crater. Low-level seismicity continued and tremor was absent. Scientists aboard an overflight on 10 February observed a new crater with high-temperature areas on the NE part, new fissures, and white steam emissions. The Alert Level remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


7 January-13 January 2015 Citation IconCite this Report


JMA reported that no eruptions occurred from Kuchinoerabujima during 5-9 January, although the level of activity remained elevated. White plumes rose 500 m above the crater. Low-level seismicity continued and tremor was absent. The Alert Level remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


10 December-16 December 2014 Citation IconCite this Report


JMA reported that no eruptions occurred from Kuchinoerabujima during 8-12 December, although the level of activity remained elevated. White plumes rose 400 m above the crater. Low-level seismicity continued and tremor was absent. Sulfur dioxide emissions increased on 9 December; measurements indicated a rate of 1,700 tons per day. The Alert Level remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


3 December-9 December 2014 Citation IconCite this Report


JMA reported that no eruptions occurred from Kuchinoerabujima during 1-5 December, although the level of activity remained elevated. White plumes rose 300 m above the crater. Low-level seismicity continued and tremor was absent. The Alert Level remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


26 November-2 December 2014 Citation IconCite this Report


JMA reported that no eruptions occurred from Kuchinoerabujima during 25-28 November although the level of activity remained elevated. White plumes rose 200 m above the crater. Low-level seismicity continued and tremor was absent. The Alert Level remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


1 October-7 October 2014 Citation IconCite this Report


JMA reported that no eruptions occurred from Kuchinoerabujima during 29 September-3 October. White plumes rose 600 m above the crater. Low-level seismicity continued and tremor was absent. The Alert Level remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


24 September-30 September 2014 Citation IconCite this Report


JMA reported that no eruptions occurred from Kuchinoerabujima during 26-29 September. White plumes rose 300 m above the crater. Low-level seismicity continued and tremor was absent. The Alert Level remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


17 September-23 September 2014 Citation IconCite this Report


JMA reported that no eruptions occurred from Kuchinoerabujima during 16-19 September. White plumes rose 600 m above the crater. Low-level seismicity continued and tremor was absent. The Alert Level remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


10 September-16 September 2014 Citation IconCite this Report


During 8-16 September JMA reported that Alert Level 3 conditions persisted at Kuchinoerabujima, but no eruptive activity was observed. Low-level seismicity continued and tremor was absent. White plumes were visible on webcamera images rising 800 m from the crater during 8-12 September and to 600 m during 13-16 September. A field survey on 12 September measured SO2 emissions that were similar to pre-eruptive levels (300 tons/day).

Source: Japan Meteorological Agency (JMA)


3 September-9 September 2014 Citation IconCite this Report


During 1-8 September, JMA reported that Alert Level 3 conditions persisted at Kuchinoerabujima, but no eruptive activity was observed. Seismicity increased during 3-5 September; tremor was occasionally detected. Based on webcamera images, white plumes were visible rising 400 m from the crater during 1-5 September and to 200 m during 5-8 September. Tremor was not detected during 5-8 September and JMA noted that poor weather conditions due to a typhoon were affecting the seismic network.

Source: Japan Meteorological Agency (JMA)


27 August-2 September 2014 Citation IconCite this Report


JMA reported that during 27 August-2 September few volcanic earthquakes were accompanied by no explosion at Kuchinoerabujima. On most days a white plume rose 50-300m above the crater rim . The Alert Level for Kuchinoerabujima remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


20 August-26 August 2014 Citation IconCite this Report


JMA reported that during 20-26 August there were few episodes of volcanic tremor and volcanic earthquakes, with no explosions at Kuchinoerabujima. On most days a white plume rose 20-400m above the crater rim. The Alert Level for Kuchinoerabujima remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


13 August-19 August 2014 Citation IconCite this Report


JMA reported that during 13-19 August tremor and quakes were accompanied by no explosions at Kuchinoerabujima. On 13 August a white plume rose 600 m and on 18 August rose 50 m above the crater rim. The Alert Level remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


6 August-12 August 2014 Citation IconCite this Report


JMA reported on 6, 12 August a white plume rose 800m and 300 m respectively above the crater rim at Kuchinoerabujima. Views of the volcano remained obscured by clouds other days, but instruments recorded volcanic seismicity and volcanic tremor. The Alert Level for Kuchinoerabujima remained at 3 (on a scale of 1-5).

Source: Japan Meteorological Agency (JMA)


30 July-5 August 2014 Citation IconCite this Report


On 3 August, JMA reported that Kuchinoerabujima erupted in the vicinity of Shin-dake crater and an overflight confirmed traces of ash on the west side of the volcano. Tokyo VAAC reported an ash plume rose to 1.5 km (5,000 ft) a.s.l. and drifted N. JMA raised the Alert Level for Kuchinoerabujima from 2 to 3 (on a scale of 1-5). On 5 August, volcanic seismicity and volcanic tremor decreased and views from a remote web camera showed a white plume 50 m above the crater rim.

Sources: Japan Meteorological Agency (JMA); Tokyo Volcanic Ash Advisory Center (VAAC)


18 March-24 March 2009 Citation IconCite this Report


On 18 March, JMA lowered the Alert Level for Kuchinoerabu-jima from 3 to 2 (on a scale of 1-5). Sulfur dioxide emissions decreased in January and the rate of deformation decreased in February. Seismicity was also low. The volcano had been in a state of unrest since September 2008.

Source: Japan Meteorological Agency (JMA)


22 October-28 October 2008 Citation IconCite this Report


On 27 October, JMA raised the Alert Level for Kuchinoerabu-jima from 2 to 3 (on a scale of 1-5). GPS measurements indicated that inflation just below the summit crater, which had started in September, was continuing. Fumarolic activity near summit had also increased. On 4 September, JMA had raised the Alert Level for from 1 to 2 because of the increased seismicity.

Source: Japan Meteorological Agency (JMA)


Bulletin Reports - Index


Reports are organized chronologically and indexed below by Month/Year (Publication Volume:Number), and include a one-line summary. Click on the index link or scroll down to read the reports.

04/1976 (NSEB 01:07) Explosion sends column 3 km high

09/1980 (SEAN 05:09) Weak ash emission

12/1980 (SEAN 05:12) Seismicity and steaming decline; 28 September eruption fissure and tephra described

03/1996 (BGVN 21:03) Increasing number of earthquakes since January

04/1996 (BGVN 21:04) Number of volcanic earthquakes continues to increase

05/1996 (BGVN 21:05) Number of volcanic earthquakes increases

07/1996 (BGVN 21:07) Seismic activity increasing since January 1996

08/1996 (BGVN 21:08) Elevated seismicity continues since January

08/1999 (BGVN 24:08) Increased seismicity, but no change at the fumaroles

09/2008 (BGVN 33:09) A rise in hazard status owing to 2008 seismicity and GPS-measured inflation

11/2010 (BGVN 35:11) Some periods of increased seismicity through 2009; white plumes

01/2013 (BGVN 38:01) Increased seismicity, 11 December 2011-5 January 2012

03/2017 (BGVN 42:03) Explosions on 3 August 2014, 29-30 May 2015 (with pyroclastic flow), and 18-19 June 2015




Information is preliminary and subject to change. All times are local (unless otherwise noted)


April 1976 (NSEB 01:07) Citation IconCite this Report


Explosion sends column 3 km high

An explosion at Shin-dake cone yielded columns of smoke 3,000 m high at about [1540] on 2 April. After 30 minutes the height of the smoke column decreased to about 200 m (twice that of usual emissions). Egg-sized volcanic ejecta fell, and ash 2 cm deep was measured in a village 3 km from the crater. The last explosion took place on 3 June 1974. [JMA reported that there was no damage.]

Information Contacts: T. Tiba, National Science Museum, Tokyo.


September 1980 (SEAN 05:09) Citation IconCite this Report


Weak ash emission

After four years of quiet, a brief, weak explosion produced a [2-3-km-high] ash cloud on 28 September at 0510. Ash fell on the sea [SW] of the volcano, missing the homes of the 12 x 5 km island's 300 residents. Activity after the explosion was limited to emission of white vapor through the end of September. Minor ash explosions have occurred in seven different years since 1966.

Information Contacts: JMA, Tokyo.


December 1980 (SEAN 05:12) Citation IconCite this Report


Seismicity and steaming decline; 28 September eruption fissure and tephra described

"After the 28 September eruption, which lasted for 1/2 hour, no additional eruptions had occurred as of the end of December. Eight scientists from Kyoto University, Kagoshima University, and the JMA observatory arrived at the island on 1 October, installing portable seismometers at five sites. The next day, they climbed to the new fissure, which was 0.6-6.0 m wide and 750 m long, trending N-S near Shin-dake crater (figure 1), active in historic time. A considerable amount of white vapor was emitted from the fissure.

Figure (see Caption) Figure 1. Sketch map of Kuchinoerabu-jima Island, 28 September 1980. Ashfall isopachs are in centimeters. Blocks fell in the stippled area. Shaded zones are inhabited. Courtesy of JMA.

"The SW sector of the volcano was covered with gray ash, l m thick near the fissure and 2 cm thick at the base of the volcano, on the coast. Blocks were scattered N and W of the fissure, the largest block measuring about 2 m in diameter. No essential ejecta were observed. The volume of ejecta was estimated at about 105 m3. Steaming decreased gradually during October, and was restricted to 10 small craters on the fissure by mid-October.

"Seismicity was relatively weak in October and November except on 4 and 9 October when swarms of small B-type earthquakes were recorded (figure 2). The JMA's seismometer was removed on 15 November because the volcano was quiet. People on the island reported no felt earthquakes, and decreasing steam activity through December. Life returned to normal for the island's 300 inhabitants soon after the 28 September eruption."

Figure (see Caption) Figure 2. Number of seismic events/day at Kuchinoerabu-jima, 1 October-15 November 1980. Courtesy of JMA.

Information Contacts: JMA, Tokyo.


March 1996 (BGVN 21:03) Citation IconCite this Report


Increasing number of earthquakes since January

According to the Sakura-jima Volcanological Observatory of Kyoto University, the number of earthquakes has increased around Shin-dake since January. The total number of earthquakes recorded was 32 in January, 40 in February, and 77 in March.

A group of young stratovolcanoes forms the E end of Kuchinoerabu-jima Island, midway between Suwanose-jima and Kyushu. Several villages on the 4 x 12 km island are located within a few kilometers of the active crater of Shin-dake and have suffered damage from historical eruptions. Shin-dake is the summit cone, and has been the site of all 13 eruptions known since 1840. The last eruption was a weak 30-minute explosion on 28 September 1980 that sent an ash plume 2-3 km high.

Information Contacts: Japan Meteorological Agency (JMA), Volcanological Division, Seismological and Volcanological Department, 1-3-4 Ote-machi, Chiyoda-ku, Tokyo 100, Japan.


April 1996 (BGVN 21:04) Citation IconCite this Report


Number of volcanic earthquakes continues to increase

According to reports from Sakura-jima Volcanological Observatory, Kyoto University, 91 earthquakes occurred around Shin-dake in April. Earthquakes have progressively increased here since January 1996. Specifically, there were 32 earthquakes in January, 40 in February, and 77 in March.

Information Contacts: Japan Meteorological Agency (JMA), Volcanological Division, Seismological and Volcanological Department, 1-3-4 Ote-machi, Chiyoda-ku, Tokyo 100, Japan.


May 1996 (BGVN 21:05) Citation IconCite this Report


Number of volcanic earthquakes increases

According to reports of Sakura-jima Volcanological Observatory, Kyoto University, 86 earthquakes occurred around Shin-dake in May. Seismicity has been increasing since January 1996.

Information Contacts: Japan Meteorological Agency (JMA), Volcanological Division, Seismological and Volcanological Department, 1-3-4 Ote-machi, Chiyoda-ku, Tokyo 100, Japan.


July 1996 (BGVN 21:07) Citation IconCite this Report


Seismic activity increasing since January 1996

Seismicity has been increasing since January 1996. According to the Sakura-jima Volcanological Observatory, Kyoto University, 75 and 25 earthquakes were detected around Shin-dake cone in June and July, respectively.

Information Contacts: Volcanological Division, Japan Meteorological Agency, 1-3-4 Ote-machi, Chiyoda-ku, Tokyo 100, Japan


August 1996 (BGVN 21:08) Citation IconCite this Report


Elevated seismicity continues since January

Seismicity has been increasing since January 1996 (BGVN 21:04, 21:05, and 21:07). According to the Sakura-jima Volcanological Observatory, Kyoto University, 62 earthquakes were detected around Shin-dake cone during August.

Information Contacts: Volcanological Division, Japan Meteorological Agency (JMA), 1-3-4 Ote-machi, Chiyoda-ku, Tokyo 100, Japan.


August 1999 (BGVN 24:08) Citation IconCite this Report


Increased seismicity, but no change at the fumaroles

The Japan Meteorological Agency (JMA) reported an increase in seismic activity on Kuchinoerabu-jima since July 1999 based on data from Sakura-jima Volcano Observatory (SVO), Kyoto University. The number of earthquakes/month increased, rising from 26 in June, to 87 in July, and to 195 in August. By mid-September, JMA and SVO had not observed any anomalous change in fumaroles in the craters of Shin-dake (the youngest volcanic cone).

Kuchinoerabu-jima is a volcanic island 12 km long and 5 km wide located ~100 km SSW of southern Kyushu Island and Sakura-jima volcano. An andesite stratovolcano, Kuchinoerabu-jima includes both an older edifice to the NW and young edifices (Furudake and Shindake cones) to the SE. Historical eruptions at Shindake were phreatic. An eruption in December 1933 killed 8 persons and injured 26.

Information Contacts: Volcanological Division, Seismological and Volcanological Department, Japan Meteorological Agency (JMA), 1-3-4 Ote-machi, Chiyoda-ku, Tokyo 100 Japan; Setsuya Nakada, Volcano Research Center, ERI, University of Tokyo, Yayoi 1-1-1, Bunkyo-ku, Tokyo 113, Japan (Email: nakada@eri.u-tokyo.ac.jp, URL: http://hakone.eri.u-tokyo.ac.jp/vrc/erup/erup.html).


September 2008 (BGVN 33:09) Citation IconCite this Report


A rise in hazard status owing to 2008 seismicity and GPS-measured inflation

Anomalous seismicity and inflation was noted at Kuchinoerabu-jima in late 2008. Seismic unrest was also reported during mid-1999 (BGVN 24:08). The island of the same name is home to ~ 140 residents and lies ~ 130 km S of the city of Kagoshima (Kyushu Island, Japan). The 19-km-diameter Kikai caldera, which is mainly submarine, sits a few tens of kilometers to the N, and is renowned for its massive eruption ~ 6,300 years ago. Kuchinoerabu Island contains a composite elongate cone made up of three closely spaced Holocene volcanoes supporting the island's S-central zone (figure 3; Geshi and Nakano, 2007; Geshi and Kobayashi, 2007).

Figure (see Caption) Figure 3. Map showing the location and geography of Kuchinoerabu-jima Island (Ryukyu Islands) south of Kyushu, Japan. The island is located ~ 15 km W of the larger circular Yaku-shima Island. The map also indicates recently active volcanoes of the region. Modified from Matsumoto and others (2007).

Increased seismicity prompted the Japan Meteorological Agency (JMA) to raise the Alert Level from 1 to 2 (on a scale of 1-5) on 4 September 2008, and to level 3 on 27 October 2008. According to JMA, GPS measurements indicated inflation just below the summit crater that had started in September was continuing in October. Fumarolic activity near the summit had also increased.

Reference. Matsumoto, T., Ueno, H., and Kobayashi, T., 2007, A new secular variation curve for South Kyushu, Japan, and its application to the dating of some lava flows: Rep. Fac. Sci., Kagoshima Univ., no. 40, p. 35-49.

Information Contacts: Volcanological Division, Seismological and Volcanological Department, Japan Meteorological Agency (JMA), 1-3-4 Ote-machi, Chiyoda-ku, Tokyo 100 Japan; Volcano Research Center (VRC-ERI), Earthquake Research Institute, University of Tokyo , Yayoi 1-1-1, Bunkyo-ku, Tokyo 113, Japan (URL: http://hakone.eri.u-tokyo.ac.jp/vrc/erup/erup.html).


November 2010 (BGVN 35:11) Citation IconCite this Report


Some periods of increased seismicity through 2009; white plumes

No eruptive activity has been reported at Kuchinoerabu-jima since a small eruption in September 1980 (SEAN 05:12). However, there have been many periods of elevated seismicity.

One such episode, beginning in early September 2008, prompted two increases in the hazard status by late October when the seismicity was accompanied by inflation and increased fumarolic activity near the summit (BGVN 33:09). The Alert Level remained at 3 (on a scale of 1-5) until 18 March 2009, when it was decreased to level 2. Sulfur dioxide emissions had decreased in January 2009, followed by a decrease in the rate of deformation.

Seismicity data during 2003-2009. Seismic data recorded by JMA between January 2003 and December 2006 indicted that the number of monthly volcanic earthquakes was typically below 200, with less than 30 tremor events. Seismicity was higher in March 2004, January-February, May, July-September, and November 2005, March-April, August, and October-December 2006, and February and April 2007 (table 1).

Table 1. Months with anomalous seismicity at Kuchinoerabu-jima between January 2003 and December 2009, showing numbers of earthquakes, tremors, and plume observations. Months with either more than 200 volcanic earthquakes or more than 30 tremors are shown, and months with earthquake swarms on specific days. All observed plumes throughout this period were white. Data courtesy of JMA.

[Skip text table]
Month         Earthquakes      Tremors     Days with    Plume height
                                            plumes          (m)

Mar 2004         315             48           --             --

Jan 2005         346             59           --             --
Feb 2005         234             36            4             40

May 2005         100             35           --             --

Jul 2005         136             58           --             --
Aug 2005         228             40           --             --
Sep 2005         201             10           --             --

Nov 2005         205              7           --             --

Mar 2006         292              7           --             --
Apr 2006         289             11           --             --

Aug 2006         221              2           --             --

Oct 2006         291             31            1             10
Nov 2006         479            100            5             30
Dec 2006         201             32            5             10

Feb 2007         174             65            2             10

Apr 2007         127             57            2             10

Sep 2008         186             49            1             30
              70 on 4 Sep

Oct 2008         133             94           20            200
Nov 2008         106             54           25            200
Dec 2008         138             39           27            200

Apr 2009         124             67           12            400
May 2009         153             96           22            300

                 177              6
Sep 2009      75 on 27 sep      28 Sep        10            200
             ~750 on 28-29    and 30 Sep

Oct 2009         131             32           10            200
                             all 1-6 Oct

A seismic swarm consisting of 70 events on 4 September 2008 resulted in the Alert Level increase already reported. The months of September-December 2008 included high numbers of tremor episodes (table 1). Large numbers of tremors were recorded again in April-May 2009. Seismicity decreased after that time, until an earthquake swarm was recorded during 27-29 September 2009 (about 150 earthquakes). Tremor events also increased briefly, with 38 between 28 September and 6 October 2009. White fumarolic plumes rising from the summit area increased in height (up to 400 m) and frequency (every 1-2 days) after September 2008 through 2009.

Information Contacts: Japan Meteorological Agency (JMA), Otemachi, 1-3-4, Chiyoda-ku Tokyo 100-8122, Japan (URL: http://www.jma.go.jp/, http://www.seisvol.kishou.go.jp/tokyo/STOCK/kaisetsu/English/level.html)


January 2013 (BGVN 38:01) Citation IconCite this Report


Increased seismicity, 11 December 2011-5 January 2012

Since a small eruption in 1980, Kuchinoerabu-jima experienced numerous periods of elevated seismicity, with volcanic earthquakes and tremor detected at least through December 2009 (BGVN 35:11). The volcano is located in the Ryukyu Island arc, off Japan’s SW coast (figure 4).

Figure (see Caption) Figure 4. A map of the major volcanoes of Japan. Kuchinoerabu-jima is at the lower left. Courtesy of USGS/CVO.

Recent monthly reports of volcanic activity from the Japan Meteorological Agency (JMA) translated into English resumed in October 2010. The only recent English-translated JMA report on Kuchinoerabu-jima available online through December 2012 was in January 2012. We know of no other recent report on this volcano’s seismic activity; therefore, this report summarizes seismicity between December 2011 and January 2012.

According to JMA, seismicity increased to a relatively high level immediately after 11 December 2011, but then decreased on 5 January 2012. On 20 January 2012, the Alert Level was lowered from 2 to 1; JMA noted that the possibility of an eruption was minimal.

During the December 2011-January 2012 period, no significant change in plume activity was observed, and plume heights remained below 100 m above the crater. According to a field survey on 11 January, infrared images (compared to images obtained in December 2011) showed no significant change in temperature distribution either at the summit or on the W slope of Shin-dake (also refered to as Shin-take), the youngest and most active cone.

Field surveys found that sulfur dioxide levels were 50 and 100 metric tons/day on 12 and 13 January 2012, respectively, which were lower than those recorded in December 2011 (200 metric tons/day on 9 December 2011).

According to JMA, continuous GPS measurements have established a baseline across Shin-dake, collecting data since September 2010. Shin-dake’s rate of change in surface deformation at the stations has been slowing since September 2011.

Information Contacts: Japan Meteorological Agency (JMA), Otemachi, 1-3-4, Chiyoda-ku Tokyo 100-8122, Japan (URL: http://www.jma.go.jp/jma/indexe.html).


March 2017 (BGVN 42:03) Citation IconCite this Report


Explosions on 3 August 2014, 29-30 May 2015 (with pyroclastic flow), and 18-19 June 2015

Intermittent ash explosions during the last century have characterized activity at Japan's Kuchinoerabujima volcano, located at the northern end of the Ryukyu Islands approximately 260 km S of Nagasaki, Japan. Brief periods of higher seismicity had been detected in the last approximately 30 years, although no explosions had been recorded since 1980 (BGVN 35:11 and 38:01). A new explosion occurred on 3 August 2014, and activity remained elevated through June 2015. Information on the latest activity is provided by the Japan Meteorological Agency (JMA) monthly reports and aviation alerts are from the Tokyo Volcanic Ash Advisory Center (VAAC).

A modest explosion from Shindake crater on 3 August 2014 caused JMA to increase the Alert Level at the volcano. Activity decreased shortly after the explosion, and only steam plumes, fumarolic activity, and occasional incandescence were observed for the next nine months. A large explosion on 29 May 2015 generated a gray-black ash plume that rose to over 9 km altitude and sent pyroclastic flows down the flanks; JMA increased the Alert Level and ordered evacuation of local residents. Activity declined after a few days, and Shindake remained quiet until a smaller explosion on 18 June 2015. The ash plume did not exceed 1 km, but ashfall was reported in towns on neighboring islands and in areas up to 80 km E. Two additional smaller explosions were reported on 18 and 19 June. Seismicity decreased significantly after the 19 June explosion, but SO2 emissions remained elevated until October 2015. The JMA did not lower the Alert Level until June 2016.

Activity during August 2014-February 2015. JMA reported an eruption from the vicinity of Shindake crater around noon local time on 3 August 2014, with a gray plume rising more than 800 m above the crater rim. This led to an increase in the Alert Level from 1 (Normal) to 3 (Do not approach the volcano) on a 5-level scale. An overflight confirmed traces of ash on the W flank. The Tokyo VAAC reported that the plume rose to an altitude greater than 1.5 km and drifted N. On 5 August, seismicity decreased, and views from a remote web camera showed a white plume rising 50 m above the crater rim. For the rest of August, seismicity remained low and steam plumes rose 50 to 800 m above the crater.

During September 2014, white plumes were generally observed 200-800 m above the crater when visibility was not obscured by weather; seismicity remained low. Scientists conducting a field survey on 12 September found SO2 emissions at 300 metric tons per day (t/d), higher than the background value of 60 t/d measured on 21 May 2014. Occasional earthquakes were recorded in October 2014, and the volume of gas emissions remained relatively high compared with before the August eruption; steam-and-gas plumes rose to 600 m above the crater rim. During field surveys on 7 and 8 October scientists measured SO2 emissions of 500 t/d. Gas emissions rose from within the Shindake crater, around a thermally anomalous fissure at the W edge of the crater, as well as from a new fumarole on the SW flank of the crater. In November, plumes continued to rise as high as 1,000 m above the crater. In another survey on 9 December 2014, scientists found that SO2 levels had increased to 1,700 t/d.

Emissions of SO2 remained high during the second half of January 2015, ranging from 1,100 to 3,100 t/d. A M 2.2 seismic event located 5 km beneath the island was recorded on 24 January. Observations made during field surveys in February confirmed continued steam emissions, and thermal anomalies from the W crater rim fissure and the new fissure on the SW flank. SO2 emissions decreased slightly from January levels to a range of 400 to 2,700 t/d in February, and steam plumes continued to rise 400-700 m above the crater.

Activity during March-June 2015. Incandescence at night was first recorded at the Shindake Crater from 24 to 31 March 2015 with a high-sensitivity camera. Aerial observation on 25 March by JMA and JCG (Japan Coast Guard) indicated a temperature rise and continued fumarolic activity around the thermal anomaly W of the crater rim. SO2 emissions remained high in March (1,000 to 3,700 t/d) and April (900 to 2,600 t/d), and steam plumes rose to 1 km above the crater. Incandescence was occasionally observed at night during April and again during 18-22 May; fumarolic activity continued along with a rise in temperature at the W and SW fissures. Steam plumes were observed rising to 600 m above the crater in May.

According to JMA, at 0959 local time on 29 May 2015, a large explosive phreatomagmatic eruption generated a gray-black ash plume that rose to over 9 km altitude and drifted ESE (figure 5). The plume was reported by the Tokyo VAAC to be at 10.9 km altitude about an hour after the eruption. The largest of several pyroclastic flows descended NW from the SW side of the crater in the Mukaehama district and reached the coast. Based on these events, JMA raised the Volcanic Alert Level to 5 (Evacuate). Aerial observation conducted on the same day (in collaboration with the Kyushu Regional Bureau of the Ministry of Land, Infrastructure, Transport and Tourism) revealed additional pyroclastic flows moving in nearly all directions from the Shindake crater (figure 6) including flows reaching halfway down the mountain to the SW and SE of the crater. Seismicity increased immediately after the eruption, but had decreased by midday.

Figure (see Caption) Figure 5. Ash plume from Kuchinoerabujima's Shindake Crater during an explosion on 29 May 2015. The plume height was reported by the Tokyo VAAC as 10.9 km altitude. Photo taken from the neighboring island of Yakushima by Itaru Takaku. Courtesy of Kyodo News and The Japan Times.
Figure (see Caption) Figure 6. Google Earth imagery dated 5 June 2015, one week after a large explosion which generated several pyroclastic flows around the summit crater at Kuchinoerabujima. Note the brown areas extending in most directions away from the summit crater (beneath the white clouds), all the way to the coast on the NW and W flanks that are the result of the pyroclastic flows that occurred on 29 May 2015. Courtesy of Google Earth.

According to a news article (The Japan Times), all residents and visitors (141 people) were safely evacuated by a ferry, coast guard ship, and helicopter to neighboring Yakushima Island (25 km SE). A resident of Yakushima reported that ash reached the island. Later that day, ash plumes rose 200 m and drifted SW.

Ash plumes continued the next day, 30 May, rising only 1.2 km. A field team observed discolored trees on the SE and SW flanks, and fallen trees near the coast on the NW flank. Cloud cover prevented views of the eruption area, but the team was able to confirm continued fumarolic activity and incandescence in the W part of the crater. Seismicity continued at low levels, and during the first week of June white plumes rose 100-400 m above the crater rim.

Another smaller eruption on 18 June 2015 caused lapilli and ash to fall on the E side of the island. Ash was reported in Yakushima Town (44 km ESE on Yakushima Island), Nishinoomote City (80 km NE on Tanegashima Island), and Nakatane Town (72 km E on Tanegashima). Small eruptions also occurred at 1631 on 18 June and at 0943 on 19 June. Tokyo VAAC reported the larger 18 June eruption, but plume heights were below 1 km, and not observed on satellite. Aerial observations on 20 June by JMA revealed no traces of new pyroclastic-flow deposits around the crater or on the flanks.

Post-eruption observations through June 2016. Emissions of SO2 remained elevated during June 2015 (800-1,700 t/d), and decreased somewhat in July to 500-700 t/d. They decreased further to 200-300 t/d in August. Increased seismicity was recorded briefly from 1-3 and 6-11 August. SO2 emissions continued to decline in September, except for a spike of 700 t/d on 10 September. Thermal infrared observations taken during a field survey in October 2015 indicated a decrease in temperature around the fissure W of the crater rim since the 29 May eruption. Emissions of SO2 remained below 300 t/d for the remainder of 2015 and no further activity was reported, although the Alert Level remained at 5. On 14 June 2016, JMA lowered the Alert Level to 3; seismic activity and SO2 flux values were below levels detected prior to the May-June 2015 eruption.

Information Contacts: Japan Meteorological Agency (JMA), Otemachi, 1-3-4, Chiyoda-ku Tokyo 100-8122, Japan (URL: http://www.jma.go.jp/jma/indexe.html); Tokyo Volcanic Ash Advisory Center (VAAC), 1-3-4 Otemachi, Chiyoda-ku, Tokyo, Japan (URL: http://ds.data.jma.go.jp/svd/vaac/data/); Google Earth (URL: https://www.google.com/earth/); The Japan Times (URL: http://www.japantimes.co.jp/news/2015/05/29/national/volcano-erupts-isle-kagoshima-prompting-evacuation-order/.

This compilation of synonyms and subsidiary features may not be comprehensive. Features are organized into four major categories: Cones, Craters, Domes, and Thermal Features. Synonyms of features appear indented below the primary name. In some cases additional feature type, elevation, or location details are provided.

Eruptive History


There is data available for 28 Holocene eruptive periods.


Start Date Stop Date Eruption Certainty VEI Evidence Activity Area or Unit
2015 May 29 2015 Jun 19 Confirmed 3 Historical Observations
2014 Aug 3 2014 Aug 3 Confirmed 1 Historical Observations Shin-dake crater
1980 Sep 28 1980 Sep 28 Confirmed 2 Historical Observations NNE-SSW fissure on E side of Shin-take
1976 Apr 2 1976 Apr 2 Confirmed 2 Historical Observations Shin-take
1974 Jun 3 1974 Jun 3 Confirmed 1 Historical Observations Shin-take
1973 Nov 5 1973 Nov 19 Confirmed 2 Historical Observations Shin-take
1972 Sep 2 1972 Sep 2 Confirmed 2 Historical Observations Shin-take
1968 Dec 21 1969 Mar 10 Confirmed 3 Historical Observations Shin-take
1966 Nov 22 1966 Nov 22 Confirmed 2 Historical Observations Shin-take
1945 Nov 3 1945 Nov 3 Confirmed 2 Historical Observations NNE-SSW fissure on E side of Shin-take
1933 Dec 23 1934 Jan 12 Confirmed 4 Historical Observations Shin-take
[ 1932 Jul 23 ] [ 1932 Jul 23 ] Uncertain 1   Shin-take
1931 Apr 2 1931 Jun 22 Confirmed 3 Historical Observations SW flank of Shin-take
1914 Jan 5 Unknown Confirmed 2 Historical Observations Shin-dake
[ 1906 ] [ 1907 ] Uncertain     Shin-dake
1841 May 23 1841 Aug 1 Confirmed 2 Historical Observations Shin-take
1840 (in or before) Unknown Confirmed 2 Historical Observations Shin-take
1560 ± 100 years Unknown Confirmed   Radiocarbon (corrected) Furu-take
1470 ± 50 years Unknown Confirmed   Radiocarbon (corrected) Furu-take
1440 ± 50 years Unknown Confirmed   Radiocarbon (corrected) Shin-take, N-1? tephra
1110 ± 75 years Unknown Confirmed   Radiocarbon (corrected) Furu-take
1100 ± 100 years Unknown Confirmed   Radiocarbon (corrected) Shin-take, N-5 tephra
0970 ± 75 years Unknown Confirmed   Radiocarbon (corrected) Furu-take
0600 ± 75 years Unknown Confirmed   Radiocarbon (corrected) Shin-take, N-6 tephra
1140 BCE ± 150 years Unknown Confirmed   Radiocarbon (corrected) Furu-take
1450 BCE ± 75 years Unknown Confirmed   Radiocarbon (corrected) Shin-take, N-m tephra
3480 BCE ± 150 years Unknown Confirmed   Radiocarbon (corrected) Furu-take
9520 BCE ± 300 years Unknown Confirmed   Radiocarbon (corrected) Furu-take

Deformation History


There is no Deformation History data available for Kuchinoerabujima.

Emission History


There is data available for 1 emission periods. Expand each entry for additional details.


Emissions during 2015 May 29 - 2015 May 29 [4 kt SO2 at 9 km altitude]

Start Date: 2015 May 29 Stop Date: 2015 May 29 Method: Satellite
SO2 Altitude Min: 9 km SO2 Altitude Max: 9 km Total SO2 Mass: 4 kt

Data Details

Date Start Date End Assumed SO2 Altitude SO2 Algorithm SO2 Mass
20150529 9.0 4.000

Photo Gallery


Steam plumes pour from a newly opened arcuate fissure on Shin-dake, the summit crater of Japan's Kuchinoerabu volcano, on September 29, 1980. A brief eruption from the new 800-m-long fissure the day before ejected blocks and ash up to 2 km above the crater. A group of young stratovolcanoes forms the eastern end of the island of Kuchinoerabu-jima in the Ryukyu Islands. All historical eruptions have occurred from Shin-dake, which has had frequent explosive eruptions since 1840 that have sometimes damaged villages located near the crater.

Photo courtesy of Japan Meteorological Agency, 1980.
See title for photo information.
Kuchinoerabu volcano rises to the SE above the fishing village of Motomura. The active cone of Shin-dake is in the center, Sankakuten-yama at the left, and Furu-dake (Huru-dake), the 649 m high point of the island, at the right. Shin-dake was formed after the NW side of Furu-dake was breached by an explosion and has been the site of frequent explosive eruptions in historical time. Several villages on the 4 x 12 km island are located within a few kilometers of Shin-dake and have suffered damage from eruptions.

Copyrighted photo by Shingo Takeuchi (Japanese Quaternary Volcanoes database, RIODB, http://riodb02.ibase.aist.go.jp/strata/VOL_JP/EN/index.htm and Geol Surv Japan, AIST, http://www.gsj.jp/).
See title for photo information.

Smithsonian Sample Collections Database


There are no samples for Kuchinoerabujima in the Smithsonian's NMNH Department of Mineral Sciences Rock and Ore collection.

Affiliated Sites
